一、产品概述
YAMATAKE EST0240Z05WBX00是YAMATAKE（山武）公司研发的智能终端/工业显示屏模块，属于控制面板系列，专为工业自动化、楼宇管理及复杂监控系统设计。其核心功能是实现智能控制、数据采集与可视化，支持多协议通信和高可靠性运行，适用于恶劣工业环境。
二、核心功能与技术参数
1.智能控制与监控
高性能处理：集成先进算法，支持高效数据采集、分析与实时可视化。
用户友好界面：配备触摸屏（2.4英寸，240×320像素，256色），支持虚拟键盘和图形化操作。
多协议通信：兼容TCP/IP、Modbus TCP/IP、Ethernet/IP、DF1、ASCII等协议，支持以太网、RS-485、RS-232接口。
2.环境适应性
防护等级：IP55（部分型号），防尘防水，适应工业恶劣环境。
工作温度：0°C至50°C（部分扩展型号支持-40°C至85°C）。
抗干扰设计：抗振动、宽温域运行，适用于电力、化工、机械等领域。
3.数据记录与存储
历史数据记录：支持长期数据存储，便于分析与报告生成。
看门狗报警：实时监测系统状态，异常时触发报警输出。
4.硬件配置
处理器：32位ARM Cortex-M3，4MB闪存+8MB RAM。
电源：24V DC，功耗2W。
尺寸与重量：30×60mm，2.36kg
三、典型应用场景
工业自动化
机器人控制、生产线监控、伺服电机驱动（支持多轴控制与编码器反馈）。
楼宇管理
照明、空调、安防系统的集成控制。
能源与电力
发电厂、变电站的设备状态监测与远程控制。
化工与制药
反应釜温度、压力监控，符合洁净环境要求。
交通与物流
仓储管理系统、自动化分拣设备的实时监控。
YAMATAKE EST0240Z05WBX00
1.Product Overview
YAMATAKE EST0240Z05WBX00 is an intelligent terminal/industrial display module developed by YAMATAKE(Shanwu)Company.It belongs to the control panel series and is specially designed for industrial automation,building management and complex monitoring systems.Its core function is to realize intelligent control,data acquisition and visualization,support multi-protocol communication and high-reliability operation,and is suitable for harsh industrial environments.
2.Core functions and technical parameters
1.Intelligent control and monitoring
High-performance processing:Integrate advanced algorithms to support efficient data acquisition,analysis and real-time visualization.
User-friendly interface:Equipped with a touch screen(2.4-inch,240×320 pixels,256 colors),supports virtual keyboard and graphical operations.
Multi-protocol communication:compatible with TCP/IP,Modbus TCP/IP,Ethernet/IP,DF1,ASCII and other protocols,and supports Ethernet,RS-485,and RS-232 interfaces.
2.Environmental adaptability
Protection level:IP55(some models),dust-proof and water-proof,adapted to harsh industrial environments.
Operating temperature:0°C to 50°C(some extended models support-40°C to 85°C).
Anti-interference design:anti-vibration,wide temperature range operation,suitable for electric power,chemical industry,machinery and other fields.
3.Data record and storage
Historical data records:Supports long-term data storage,which facilitates analysis and report generation.
Watchdog alarm:monitors the system status in real time and triggers the alarm output when abnormalities are triggered.
4.Hardware configuration
Processor:32-bit ARM Cortex-M3,4MB flash memory+8MB RAM.
Power supply:24V DC,power consumption 2W.
Dimensions and weight:30×60mm,2.36kg
3.Typical application scenarios
Industrial automation
Robot control,production line monitoring,servo motor drive(supports multi-axis control and encoder feedback).
Building Management
Integrated control of lighting,air conditioning and security systems.
Energy and Electricity
Equipment status monitoring and remote control of power plants and substations.
Chemical Industry and Pharmaceuticals
The temperature and pressure of the reactor are monitored,and meet the requirements of the clean environment.
Transportation and Logistics
Real-time monitoring of warehousing management systems and automated sorting equipment.
