描述
一、产品概述
YASKAWA CP-317/218IF是安川电机（YASKAWA）推出的工业通信模块，属于PLC（可编程逻辑控制器）系统的核心组件，专为工业自动化控制设计。其核心功能是实现设备间数据传输与通信协议转换，支持多协议兼容和高可靠性通信，适用于复杂工业环境下的实时控制与监控。
二、核心功能与技术参数
1.通信能力
协议支持：
Modbus RTU/TCP/IP：支持标准工业通信协议，实现与PLC、HMI、上位机的无缝对接。
Profibus-DP：适用于分布式控制系统，支持高速数据交换。
接口类型：
以太网接口（10/100Mbps自适应）：支持工业以太网通信。
RS-232/RS-485串口：兼容短距离与长距离通信需求。
2.电气参数
电源要求：
输入电压：宽范围DC 5-35V（部分型号支持AC 24V）。
功耗：典型值约2-3W，低功耗设计适用于嵌入式场景。
信号输入输出：
模拟量输入：支持4-20mA、0-10V、0-30V等信号范围，精度达0.01%。
数字量输入/输出：支持多路开关量信号，兼容24V DC有源/无源信号。
隔离保护：内置信号隔离模块，抗干扰能力强。
3.物理特性
尺寸与安装：
标准工业模块尺寸（如19英寸机架安装），支持导轨安装。
重量：约60Kg（具体型号可能略有差异）。
环境适应性：
工作温度：-40°C至85°C（宽温域设计）。
防护等级：IP65/IP67（部分型号），防尘防水，适应恶劣工业环境。
4.扩展性
模块化设计：支持通过扩展接口连接其他I/O模块或定制化子板。
冗余配置：可选双电源冗余，提升系统可靠性。
YASKAWA CP-317/218IF
YASKAWA CP-317/218IF
1.Product Overview
YASKAWA CP-317/218IF is an industrial communication module launched by Yaskawa Motor(YASKAWA).It is a core component of the PLC(Programmable Logic Controller)system and is specially designed for industrial automation control.Its core function is to realize data transmission and communication protocol conversion between devices,support multi-protocol compatibility and high-reliability communication,and is suitable for real-time control and monitoring in complex industrial environments.
2.Core functions and technical parameters
1.Communication capability
Protocol support:
Modbus RTU/TCP/IP:supports standard industrial communication protocols to achieve seamless connection with PLC,HMI,and host computers.
Profibus-DP:Suitable for distributed control systems and supports high-speed data exchange.
Interface type:
Ethernet interface(10/100Mbps adaptive):supports industrial Ethernet communication.
RS-232/RS-485 serial port:compatible with short-distance and long-distance communication requirements.
2.Electrical parameters
Power requirements:
Input voltage:wide range DC 5-35V(some models support AC 24V).
Power consumption:Typical value is about 2-3W,low power consumption design is suitable for embedded scenarios.
Signal input and output:
Analog input:supports signal ranges such as 4-20mA,0-10V,0-30V,and the accuracy reaches 0.01%.
Digital input/output:Supports multiple switching signal and is compatible with 24V DC active/passive signals.
Isolation protection:Built-in signal isolation module,strong anti-interference ability.
3.Physical characteristics
Size and Installation:
Standard industrial module size(such as 19-inch rack mounting),supports rail mounting.
Weight:About 60Kg(specific models may vary slightly).
Environmental adaptability:
Operating temperature:-40°C to 85°C(wide temperature range design).
Protection level:IP65/IP67(some models),dust-proof and water-proof,adapted to harsh industrial environments.
4.Extensibility
Modular design:supports connecting other I/O modules or customized daughterboards through the extension interface.
Redundant configuration:optional dual power supply redundancy to improve system reliability.
