描述
YASKAWA CIMR-HB4A0260是安川电机旗下H1000系列的重负载变频器，专为高功率、高可靠性工业场景设计。以下是其核心参数、技术特点及应用领域的详细分析：
一、基本参数
型号与功率
-型号：CIMR-HB4A0260（110kW）
-额定电压：380V/400V（400V级）
-适配电机功率范围：110kW（超重载模式）
-防护等级：IP00（标准型）或NEMA Type 1（带防护型）。
主电路与控制方式
-电流矢量控制（VVC）为主控模式，支持同步电机与感应电机通用驱动
-开关方式：PWM控制，支持直流电抗器（标配）及高次谐波抑制滤波器（选购）。
二、技术特点
高性能驱动能力
-高起动转矩：在1Hz时可输出150%额定转矩（需绝对值编码器配合）
-高响应速度：带PG控制时，速度响应可达50Hz以上，适合高动态负载。
转矩控制与保护
-精密转矩限制：通过矢量控制实现±5%转矩精度，可保护机械免受突发负载冲击
-安全停止功能：支持紧急切断输入电源或内部驱动回路，符合欧洲安全标准。
环保与节能
-Swing PWM技术：降低噪音并抑制电磁干扰
-RoHS认证：符合欧盟有害物质限制指令
-高效运行模式：适用于同步电机时比感应电机更节能。
三、应用领域
重型工业
-钢铁厂、电厂、煤矿等场景的提升机、输送机械
-同步电机驱动（如鼓风机、压缩机）。
通用机械
-金属加工机械、搬运机械、塑料挤出机
-需高精度速度控制的流体机械（如泵、风机）。
特殊环境
-耐油、耐振动设计，适用于恶劣工业现场。
四、通信与扩展功能
标准通信协议
-RS-422/RS-485接口，支持Modbus-RTU协议
-选购Profibus-DP、CANopen等现场总线模块。
编程与调试
-DriveWorksEZ：通过USB连接计算机，实现可视化编程与参数自动生成
-在线自学习：运行中动态调整电机特性，适应温度变化或负载波动。
YASKAWA CIMR-HB4A0260 is a heavy-duty inverter of the H1000 series of Yaskawa Electric,designed for high-power and high-reliability industrial scenarios.The following is a detailed analysis of its core parameters,technical features and application areas:
I.Basic parameters
Model and power
-Model:CIMR-HB4A0260(110kW)
-Rated voltage:380V/400V(400V level)
-Applicable motor power range:110kW(super heavy load mode)
-Protection level:IP00(standard)or NEMA Type 1(protected type).
Main circuit and control mode
-Current vector control(VVC)is the main control mode,supporting universal drive of synchronous motors and induction motors
-Switching mode:PWM control,supporting DC reactors(standard)and high-order harmonic suppression filters(optional).
2.Technical Features
High-performance drive capability
-High starting torque:150%rated torque can be output at 1Hz(absolute encoder required)
-High response speed:With PG control,the speed response can reach more than 50Hz,suitable for high dynamic loads.
Torque control and protection
-Precision torque limit:±5%torque accuracy is achieved through vector control to protect the machine from sudden load impact
-Safe stop function:Supports emergency cut-off of input power or internal drive circuit,in line with European safety standards.
Environmental protection and energy saving
-Swing PWM technology:Reduce noise and suppress electromagnetic interference
-RoHS certification:Complies with the EU Restriction of Hazardous Substances Directive
-Efficient operation mode:More energy-efficient than induction motors when applied to synchronous motors.
3.Application areas
Heavy industry
-Hoists and conveying machinery in steel plants,power plants,coal mines,etc.
-Synchronous motor drive(such as blowers,compressors).
General machinery
-Metal processing machinery,handling machinery,plastic extruders
-Fluid machinery that requires high-precision speed control(such as pumps,fans).
Special environment
-Oil-resistant and vibration-resistant design,suitable for harsh industrial sites.
IV.Communication and expansion functions
Standard communication protocol
-RS-422/RS-485 interface,support Modbus-RTU protocol
-Optional fieldbus modules such as Profibus-DP and CANopen.
Programming and debugging
-DriveWorksEZ:Connect to the computer via USB to achieve visual programming and automatic parameter generation
-Online self-learning:Dynamically adjust the motor characteristics during operation to adapt to temperature changes or load fluctuations.
